| EXTRUSION ALLOY PROPERTIES |
| HEAT-TREATABLE WROUGHT ALLOY
6063 |
COMMERCIAL DESIGNATION: 6063
STANDARD
REF. No(UNI – ITALY): H9
REF. No(ONORM - AUSTRIA): AlMgSi0,5
REF. No(DIN - GERMANY): AlMgSi0,5
REF. No(JIS - JAPAN): A6063
REF. No(UNE - SPAIN): L-3441
REF. No(AA ASTM - USA): 6063 |
|
Alloy
|
Cu
max
|
Fe
max
|
Mg
|
Si
|
Mn
max
|
Zn
max
|
Ti
max
|
Cr
max
|
Total impurities except
Fe+Ti max
|
Al
|
|
Theoretic semis
|
-
0,10
|
-
0,35
|
0,55
0,48-0,6
|
0,55
0,52-0,6
|
-
0,1
|
-
0,1
|
-
0,10
|
-
0,10
|
-
0,30
|
remainder
remainder
|
| Density:2,70 kg/dm
3
Melting temperature: 600 °C
Specific heat at 100 °C: 0,22 cal/g -1°C-1
Thermal conductivity at 20 °C
O: 0,42 cal/sec cm °C
|
Coefficient of
linear expansion:
20 to 100 °C 23 . 10 -6-°C
-1
20 to 200 °C 24 . 10 -6-°C
-1
20 to 300 °C 25 . 10 -6-°C
-1
Specific electrical resistance at 20 °C:
T6:3,14 m W
cm
Modulus of elasticity: 6700 Kg/mm
2
|
|
Type of extrusion
|
Description
|
Symbol
|
Section max mm2
|
Ult. Tensile strenght Kg/mm2
|
Yield point Kg/mm2
|
Elongation %
|
Brinell hardness HB Kg/mm2
|
|
any extrusion
|
Heat-treated
Heat-treated Heat-treated
|
T1
T5
T6
|
12000
12000
12000
|
15-20
20-28
21-28
|
8-15
17-23
18-25
|
15-20
12-17
11-17
|
40-55
70-90
75-95
|
